IPVDS-700-ED
4K IP Video Wall Controller
IPVDS-700-ED is a 4K HDMI IP Video Wall Control solution for simultaneously playing multiple sources of audio/video, such as PC, media player, Blu-ray, etc, on a video wall and other displays. It also splits a high-quality video into multiple videos and plays it on the video wall and other displays.
IPVDS-700-ED provides the optimal solution for large video wall systems in control rooms, security and traffic control; it can be also be used in general fields like conference, education or presentation rooms. The PC program can be used for host allocation and previewing and is equipped with drag and drop operation with simple mouse use. Users can easily merge, split, overlay, and clear for host allocation; there is a preview scene on the ‘Layout Manager’ before application to real display monitors.
Features
TCP/IP base IP network: Gigabit Ethernet
Support up to 4K (3840x2160@30Hz 4:4:4 or 3840x2160@60Hz 4:2:0) input resolution
Support up to 4K (3840x2160@30Hz 4:4:4) output resolution
Supports Analog/HDMI audio input and output
Fast switching time / low video latency
Transmits HDMI/DVI video, audio, USB, RS-232, IR signal over IP network
Provides HDMI loop-thru port for local display(Up to 4K 60Hz 4:2:0)
Provides merge, overlay and split function on multiple video wall layout of PC program
Supports up to 256 displays (16x16 - 4x64 - 1x256) video wall and multi-sources
Supports M:N virtual matrix
Supports 802.3af standard PoE (Power-over-Ethernet)
PC application for controlling video wall and individual displays
Provides drag and drop operation for host allocation
Provides allocate, merge, split, overlay function on the layout management
Provides preview screen before applying it to actual displays
Provides up to 99 pre-sets for the user defined layout (save/load)
Pre-set scheduling function: Sequential mode(dwell time based)
Bezel compensation in 0.1mm
